Home / Products / High Vacuum Suction Units


Changeover Lever

to shift from one jar to other

Electronic Sensor

To prevent splash droplets to enter the pump. The motor will stop and a beep will indicate this.

Polysulfone (PSU) Jars

2 x 4 Ltrs. (PSU) Jars for better autoclavaility

Utility Space

To keep patient tube, catheters, foot switch when the machine is not in use.

Square Gauge

for easy readability

Oil-free Diaphragm Pump

No-oil maintenance free diaphragm pump.

Maximum Vacuum

Max. vacuum

-600 mm Hg

Liter per minute


60 Ltrs / min

Noise Level

55 dB A ± 3

Net Weight

Net Weight

22 Kg



46 x 34 x 86 cms

Suction Jars


2 x 4 Ltrs. Polysulfone (PSU) Jars

  Housing Plastic moulded on two wheels with foot switch & changeover lever
  Max. Vacuum / LPM -600 mm Hg, 60 Ltrs / min
  Pump Type Double Diaphragm pump
  Jars 2 x 4 Ltrs. Polysulfone (PSU) Jars
  Filter Bacterial Filter Autoclavable / Reusable
  Tubing 10 mm ID x 2 mtr. (PVC)
  Vacuum Gauge 6.25 cm dia 0-760 mm Hg
  Power Supply 220 V AC, 50 / 60 Hz, 180 Watt
  Noise Level 55 dB A ± 3
  Dimensions 46 x 34 x 86 cms
  Net Weight 22 Kg
  Overflow Safety Mechanical & Electronic Sensor
  Optional 110 V
  Certifications CE, IEC 60601-1-2012

Technical Information for Flovac 50
Instruction Manual for Flovac 50
