HEMOCUT VAC VS1 Vessel Sealing Electrosurgical Unit

60,000.00

The HEMOCUT VAC VS1 Vessel Sealing Electrosurgical Unit delivers advanced vessel sealing, precise cutting, and reliable coagulation, ensuring efficiency and safety in surgical procedures.

Dual Mode Efficiency:
Bipolar <60 mA RMS , Monopolar <150 mA RMS Current Control

  • 40-User Program
  • Electrosurgery Through Technology
  • Sure Precise Seal
  • Intel Tissue Response

MAIN APPLICATIONS
Suitable for ophthalmic, laparoscopic, endoscopic, GI, orthopedic, oncology, gynecology, urology, thoracic, and other open or minimally invasive surgeries, including plastic, neuro, ENT, spine, and cardiac.

SKU: 02-2-1-1 Category:

PRODUCT FEATURES

Vessel Sealing Mode: Pure Sine wave 440 kHz

Seal Modes & Output Power (at 100Ω, CF1.5): Soft-Seal: 120 W, Med-Seal: 200 W & Rapid-Seal: 350 W

PPQM System

PPQM System

Measuring Frequency: 85 kHz ± 10 kHz Measuring current: < 10 μα
Dual Area Patient Return Electrode: 5-135Ω
Single Area Patient Return Electrode: < 10Ω

Overflow Safety

Leakage Current

HF Leakage: Monopolar <150 mA RMS Bipolar <60 mA RMS
Low Frequency: Normal polarity,intact ground: < 10μA
Normal polarity, ground open: < 50μA

Operating Voltage

190–260 Volt, 50Hz AC (Optional: 90–120 Volts, 60Hz AC)

Safety Standards

Safety Standards

Classification according to the EC-Directive 93/42/EEC: Class Ilb
General Safety Standards: IEC 60601-1-1, IEC 60601-2-2
EMI/EMC Compatibility Standard: IEC 60601-1-2
IS Safety Standard: 15 7583

Dimension

Dimensions

L x W x H: 350 × 350 × 130 mm

Net Weight

Net Weight

6.5 kg

Hemocut VS1 Output characteristics

Modes Maximum P-P Voltage Rated Load (OHMS) Maximum Power (W) Crest Factor* (Typical)
Monopolar Cut
Pure9005004001.5
Blend I11005003002.1
Blend II12005002502.4
Blend III13005002002.8
Blend IV13005001503.1
Monopolar Coag.
Soft16005002503.5
Dessicate18005002003.8
Force21005001504.2
Spray30005001006.8
Bipolar
Micro320100701.5
Standard460100901.5
Macro/Cut6001001201.5

Technical Information for HEMOCUT VAC VS1
